Wurlitzer MLM

The Wurlitzer MLM (model 101) was produced as a learning tool for students. It is a keyboard inside of an ABS plastic case, which closes up completely when the keyboard is not in use. It has very basic electronics and lacks any features typically found in an organ, such as tremolo or different tones.

It wasn’t explicitly intended as a combo organ, but today it fits the description due to its organ-like sound and portability.

The technical drawings for the Wurlitzer MLM that we currently have scanned include:

  • 206547 (Back plate, handle, for 101)

  • 206548 (Clamp, speaker, for 101)

Technical engineering drawing of a back plate handle with measurements and annotations, including dimensions and material specifications, from a blueprint by The Wurlitzer Co.
A detailed technical engineering drawing of a back plate with handle, depicting measurements and specifications for manufacturing, with annotations and notes.
Technical engineering drawing of a clamp speaker with annotated measurements and specifications, produced by The Wurlitzer Co.
