FEATURESCassette recorder
Certain models of Wurlitzer organ had a built-in cassette recorder. Users could record their own performances, or insert a tape and play along to it.
There is very little documentation about the inner workings of the cassette recorders, because the cassette unit itself was manufactured by Bell & Howell, not Wurlitzer. However, there are many drawings of the mounting and connection of the recorders in various models of Wurlitzer organs, as well as quality control documentation.
Interested in more cassette recorder documents? Request them here.
9400 CASSETTE RECORDER
FOR ELECTRONIC ORGANSSPECIFICATIONS
TBD
FEATURES
TBDCorinth Division Engineering Specifications
Cassette kit
Part name: Housing assembly - closed end
Model: 9400
Date: September 23 1975
Diazo print with color photographsSet up and testing procedures
Cassette recorder
Part no.: 657925
Date: December 29 1970
Typescript on paperProcedure no.: 201-5-59
Part no.: 142547
Part name: Cassette rec. & play
Model: All Sprite models
Date: January 15 1975
Pages: 1 of 2
Pencil drawing on drafting vellumPart no.: 506918
Part name: Setting up instructions - sheet 3
Model: 351
Date: September 17 1970
Diazo printPart no.: 506928
Part name: Mounting strap - cassette
Model: 4022D, 4035
Date: August 20 1970
Diazo printPart no.: 507142
Part name: Outer box shipping container - cassette w/ drawer
Model: N/A
Date: January 11 1971
Diazo print
