Wurlitzer 4075
The Wurlitzer 4075 is an organ with solid state electronics.
Because the archive originated in the engineering department, some models do not have the kind of explicit specifications that are more common in marketing materials or user manuals. Help us fill out this description by contributing your knowledge or documents to the archive.
We may find more 4075 records as we scan the tens of thousands of pages in the archive. Looking for more 4075 organ drawings? Request them here.
4075 ELECTRONIC ORGAN
TRANSISTOR DIVIDER ORGANSPECIFICATIONS
TBD
AMPLIFIER
TBDFEATURES
TBDPart no.: 655875
Part name: Angle bracket - floor support
Model: 4075
Date: February 8 1967
Diazo print
Parts History Record (1)Part no.: 655876
Part name: Pivot shaft stop tablet
Model: 4075
Date: June 23 1967
Diazo print
Parts History Record (1)Part no.: 655878
Part name: Grille cloth
Model: 4075
Date: June 23 1967
Diazo print
Parts History Record (1)
Material Evaluation Report (1)
Approved source card (1)Part no.: 655903
Part name: Ornament
Model: 4075
Date: June 26 1967
Diazo print
Parts History Record (1)
Material Evaluation Report (3)Part no.: 656037
Part name: Shield - keyblocks
Model: 4075
Date: July 6 1967
Diazo print
Parts History Record (1)
Material Evaluation Report (1)
Attached material sample
