Wurlitzer 4570
The Wurlitzer 4570 is an organ with solid state electronics.
Because the archive originated in the engineering department, some models do not have the kind of explicit specifications that are more common in marketing materials or user manuals. Help us fill out this description by contributing your knowledge or documents to the archive.
We may find more 4570 records as we scan the tens of thousands of pages in the archive. Looking for more 4570 organ drawings? Request them here.
4570 ELECTRONIC ORGAN
TRANSISTOR DIVIDER ORGANSPECIFICATIONS
TBD
AMPLIFIER
TBDFEATURES
TBDPart no.: 659433
Part name: Support bracket - r.h.
Model: 4570
Date: May 10 1971
Diazo print
Parts History Record (1)Part no.: 659434
Part name: Support bracket - l.h.
Model: 4570
Date: May 6 1971
Diazo print
Part History Record (1)Part no.: 659436
Part name: Bulk extrusion - straf
Model: 4570
Date: May 3 1971
Diazo printPart no.: 659732
Part name: Buss wire
Model: 4570
Date: November 19 1971
Diazo printPart no.: 659743
Part name: Tape - hot stamping
Model: 4570
Date: May 13 1971
Diazo print
Approved source card (1)Continue browsing
