Wurlitzer 4150 & 4150A
VIEW SIMILAR: 4102 | 4200 & 4250 | 4017 The “A” designated a change in amplifier layout. More details here.
Looking for more 4100A organ drawings? Request them here. Contact us if you would like to contribute information or documents about this model to the archive.
WURLITZER 4150
VACUUM TUBE ORGANSPECIFICATIONS
UPPER MANUAL: 44 keys
LOWER MANUAL: 44 keys
PEDALS: 13 keys
DIMENSIONS
HEIGHT: 35 1/4"
WIDTH: 46 3/16"
DEPTH: 23 1/3"
WEIGHT: ~215 lbs
BENCH WEIGHT: ~15 lbs
AMPLIFIER
POWER CONSUMPTION: 235 W
POWER OUTPUT: 26 WFEATURES
Automatic Tone Controls
Master volume (Full//Soft)
Pedal Sustain (Medium/Long)
Vibrato depth (Normal/Full)
Vibrato speed (Slow/Fast)
COUPLERS
Upper to Lower 8'
Upper 8' - Off
Upper to Upper 16'
Upper to Upper 8'Part no.: 501005
Part name: Actuator - bass button
Model: 4150
Date: June 17 1959
Diazo printPart no.: 501006
Part name: Contact wire - switch - bass
Model: 4150
Date: June 17 1959
Diazo printPart no.: 501007
Part name: Contact wire - switch - bass
Model: 4150
Date: June 17 1959
Diazo print
