Wurlitzer 420A tone cabinet
The Wurlitzer 420A was a tone cabinet manufactured in the 1960s as an accessory to Wurlitzer organs. It contained a rotary speaker and provided additional amplification.
We do not currently have detailed specifications for the Wurlitzer 420A. It is also unclear what the difference is between the 420 and the 420A tone cabinet. If you have information about this tone cabinet, let us know.
Looking for more 420A tone cabinet drawings? Request them here.
420A TONE CABINET
FOR ELECTRONIC ORGANSSPECIFICATIONS
TBD
AMPLIFIER
TBDFEATURES
TBDPart no.: 504647
Part name: Label - tropicalized
Model: 420A
Date: December 22 1964
Diazo printPart no.: 653009
Part name: Socket & bracket assembly
Model: 420A
Date: June 17 1964
Diazo printPart no.: 653015
Part name: Silk screen
Model: 420A
Date: June 16 1964
Diazo printPart no.: 653018
Part name: Cable
Model: 420A
Date: June 11 1964
Diazo printPart no.: 653021
Part name: Cable
Model: 420A
Date: June 11 1964
Diazo printPart no.: 653029
Part name: Plug & cable assembly
Model: 420A
Date: June 15 1964
Diazo printPart no.: 653031
Part name: Cable & plug assembly
Model: 420A
Date: June 16 1964
Diazo printPart no.: 653033
Part name: Spring
Model: 420A
Date: June 20 1964
Diazo print
