Wurlitzer 4600
The Wurlitzer 4600 is a continuous free reed organ manufactured in the 1950s.
Information about the 4600 is scarce. Because the archive originated in the engineering department, some models do not have the kind of explicit specifications that are more common in marketing materials or user manuals. Help us fill out this description by contributing your knowledge or documents to the archive.
We may find more 4600 records as we scan the tens of thousands of pages in the archive. Looking for more 4600 organ drawings? Request them here.
4600 ELECTRONIC ORGAN
FREE REED ORGANSPECIFICATIONS
TBD
AMPLIFIER
TBDFEATURES
TBDPart no.: 19154
Part name: Felt - pedal key rail
Model: 4600
Date: February 14 1953
Diazo print with attached samplePart no.: 19155
Part name: Felt - pedal key rail
Model: 4600
Date: February 13 1953
Diazo printPart no.: 19156
Part name: Felt - pedal key rail
Model: 4600
Date: February 13 1953
Diazo printPart no.: 19157
Part name: Felt - pedal key rail
Model: 4600
Date: February 12 1953
Diazo printPart no.: 19158
Part name: Felt - pedal key rail
Model: 4600
Date: February 13 1953
Diazo printPart no.: 19190
Part name: Locating plate & pin assembly - r.h.
Model: 4600
Date: February 19 1953
Diazo print
Parts History Record (1)
Incoming Quality Control History Card (1)Part no.: 19277
Part name: Eyelet
Model: 4600
Date: February 25 1953
Diazo print
Parts History Record (1)
Incoming Quality Control History Card (1)Part no.: 19343
Part name: Lens - pilot light
Model: 4600
Date: March 3 1953
Diazo printPart no.: 19345
Part name: Plug & cable assembly
Model: 4600
Date: March 3 1953
Diazo printPart no.: 19391
Part name: Insulated mounting strip
Model: 4600
Date: March 5 1953
Diazo print
Parts History Record (2)
Approved source card (1)
Inter-Company Correspondence (1)Part no.: 61262
Part name: Belt & retainer assembly
Model: 4600
Date: February 26 1954
Diazo print
Photocopy with handwritten notes
